Features:
- Compact design
- Dedicate to liner-free thermal paper
- Paper holding sensor
- Rich interface options: Ethernet,USB, Serial
- Easy operation of paper loading
- Front paper out/Top paper out
Applications:
- Retail
- Medical
- Hospitality
- Warehousing/Logistics
Item |
Specifications |
|
Print method |
Direct thermal line printing |
|
Resolution |
203 X 203 DPI |
|
Print speed |
170mm/s (liner-free label) |
|
Print width |
80mm |
|
Memory |
Flash: 4M, RAM:16M |
|
Interface |
USB+Serial+Ethernet;USB+Serial;USB+Ethernet (optional) |
|
Cash drawer control |
RJ11 interface, can select to control 1-2 cash drawers |
|
Sensor |
Paper end sensor/ Top cover open sensor/ TPH overheating protection/ Paper hold sensor |
|
Software |
Windows/Linux Driver, Android/iOS SDK, OPOS |
|
|
Barcodes Fonts Graphics |
Barcodes |
1D:UPC-A, UPC-E, JAN8 (EAN8), JAN13 (EAN13), CODE 39, CODE 93, CODE 128, ITF, CODABAR |
Fonts |
Font A 12 ✕ 24, Font B 9 ✕ 17, kanji 24 ✕ 24 |
|
Character set |
95 Alphanumeric,14 types of international characters,traditionalChinese,simplified Chinese, Japanese, Korean, English (optional) |
|
Character modification |
Underline, emphasize, reverse, enlarge (2-6 X) |
|
Paper |
Paper type |
Liner-free label |
Paper thickness |
0.06-0.08mm |
|
Paper width |
82.5±0.5mm； |
|
Paper roll OD |
Max.Φ80mm |
|
Paper cut |
Partial cut |
|
Reliability |
Print head lifetime |
12.5% duty cycle sample meets 100 km life requirement |
MTBF |
5,000 hours |
|
Power supply |
Input |
100~240V AC |
Output |
24V DC |
|
Environment |
Operation conditions |
5°C～45°C |
Storage conditions |
-40 °C ～ 60°C RH (40°C) |
|
Physics Spec. |
Dimension |
130.7mm(L) ×127.5mm (W) ×127.5mm (H) |
Weight |
0.97Kg |
|
Standards |
Certification |
UL/FCC/IC/CB/CE/UKCA |
